Cherry MultiBoard MY 7000 - Keyboard Options

18
Codes for manual programming
1 Keyboard options
2 Magnetic card options
Options Programming string
(by keystroke)
Comment Default
1st 2nd 3rd 4th
Define delay time
(for barcode, magnetic
card, keys)
Z 1 0-9 Delay time between the codes:
0 = w/o delay; 1 = 2 ms; 2 = 4 ms;
3 = 6 ms; 4 = 8 ms; 5 = 10 ms; 6 = 15 ms;
7 = 20 ms; 8 = 40 ms; 9 = 70 ms
6
(15 ms)
Send downcode only:
Transmission of
downcodes only (for
barcode & magnetic card)
Z 2 Y/N Y = transmission of downcode only;
N = transmission of both down- & upcodes
N
Keyclick Z 3 Y/N Y = enable; N = disable N
Online programming:
Viewing the information
output during manual prog.
mode
Z 4 Y/N Y = enable; N = disable Y
Output of configuration
settings
Z 5 Output of current configuration settings
(e.g. to an open editor application)
Options Programming string
(by keystroke)
Comment Default
1st 2nd 3rd 4th
TrioVing/Gemini
card decoding
D 1 Y/N Y = enable; N = disable Y
SiPass/AAMVA
card decoding
D 2 Y/N Y = enable; N = disable Y
JIS2 card decoding D 4 Y/N Y = enable; N = disable Y
ISO card decoding D 5 Y/N Y = enable; N = disable Y
Bidirectional
reading
D 3 Y/N Y = card swipe right to left and vice versa
N = card swipe right to left only
Y
Buzzer for good
read
D 6 Y/N Y = buzzer on; N = buzzer off Y
Track 1 reading J 1 Y/N Y = enable; N = disable Y
Track 2 reading J 2 Y/N Y = enable; N = disable Y
Track 3 reading J 3 Y/N Y = enable; N = disable Y
Stop character
check
(per track)
J 5 Y/N Y = If stop character is correct the track
data is transmitted (the stop character itself
is not output). If stop character is incorrect
or not found on card the track data is not
transmitted.
N = Data is transmitted without verification
of the stop character.
Y
LRC checksum
verification
J 6 Y/N Y = If LRC checksum is correct data is
transmitted (the LRC byte itself is not
output).
N = Data is transmitted without verification
of LRC checksum.
Y
