Installation
■ Q6: 2 pairs of parallel connected Speakon sockets, each pair carrying the output of 2 channels,
wired as follows:
CHANNEL A: 1+ = HOT (OUTPUT) 1- = GROUND
CHANNEL B: 2+ = HOT (OUTPUT) 2- = GROUND
CHANNEL C: 1+ = HOT (OUTPUT) 1- = GROUND
CHANNEL D: 2+ = HOT (OUTPUT) 2- = GROUND
High voltages may be present at output terminals during operation and for a period
afterwards
Do not connect the amplifier output to any other amplifier output or to any other
quipment except a loudspeaker system.
Suggested speaker ratings, per amplifier channel:
Model 16Ω 8Ω 4Ω 2Ω
A750 175W 325W 550W -
A1000 / Q6 250W 400W 800W -
A1500 600W 1200W 2000W -
A2000 250W 400W 800W 1600W
A2500 600W 1200W 2000W 3500W
A3000 350W 650W 1200W 2100W
A5000 600W 1200W 2000W 3500W
A6000 800W 1600W 2650W 4000W
Q900 350W 650W 1200W 2100W
A2500 / A5000 / A6000 amplifiers incorporate an adjustable output limiting control, concealed
behind the front panel. Consult an authorised Chevin dealer if you wish to make use of this
feature.
Correct total loading for the amplifiers is as follows. Multiple speakers are connected in parallel:
A750 / A1000 / A1500 / Q6 (per channel):
4 or less speakers of 16Ω
OR 2 or less speakers of 8Ω
OR 1 speaker of 4Ω
Do not use a system with a total impedance per channel of under 4Ω
A2000 / A2500 / A3000 / A5000 / A6000 / Q900 (per channel):
8 or less speakers of 16Ω
OR 4 or less speakers of 8 Ω
OR 2 or less speakers of 4Ω
OR 1 speaker of 2Ω
Do not use a system with a total impedance per channel of under 2Ω
Installation
5
Loudspeaker
Power Ratings
Pre-Set
Limiter -
A2500/A5000/
A6000
Loudspeaker
Impedance
Speakon Socket
Wiring, continued
▲
Warning:
▲
Warning:
▲
Warning:
▲
Warning:
