76 Infotainment System
Navigation Symbols
The following symbols are the most
common symbols that appear on a
map screen.
The vehicle is shown as this
symbol. It shows the position and
direction the vehicle is moving on
the map.
This symbol marks the final
destination of the planned route.
This symbol appears on the map for
a planned waypoint.
The waypoint symbol is numbered
from 1 through 5 depending on how
many waypoints have been set.
This symbol indicates the distance
to the final destination. It only
appears when the time symbol
does not appear.
This symbol indicates the distance
and the estimated time remaining to
the final destination or arrival time,
depending on the option selected.
See Navigation Set Up on page 61
for more information.
