Page 15>"-&#$95<19)(&?2$+#1"<+@&,($)+$&9)((&ABCCCBCDDBEFGF/ITEM 56708
HI>;JKLM;NIJOL!PIO!J;!I!Q; H;JRM
N$,()91<8$&'()*$
SIN!O!T
JL&N;VRQ;&NOHY&L>&H;NOLRH&O!jRNK%&
N$#2-<&82)-*&#"&"-181<)(&,"+1#1"<&)<*&+$92-$&1<&,()9$&)7#$-&-$,()91<8&4()*$/
1. Unplug the tool from its power source.
2. Lock the blade assembly in the raised
position by pushing in the Locking Pin.
3. Use the supplied Wrench to remove
the Center Cover Fixing Bolt holding
the Center Cover in place by turning it
counterclockwise. [H$$&>182-$&Q/\
>182-$&Q%&&N$:"W1<8&'"(#
4. Remove the Safety Screw. [H$$&>182-$&V/\
>182-$&V%&&N$:"W1<8&H)7$#.&H9-$3
5. Raise the Blade Guard and Center Cover.
[H$$&>182-$&;/\
>182-$&;%&&N)1+$&'()*$&T2)-*
6. While holding in the Arbor Lock Button,
use the Wrench to loosen the Arbor Bolt
by turning it clockwise. [H$$&>182-$&>/\
>182-$&>%&&I-4"-&'"(#
!"#$% The Arbor Bolt has a left hand thread,
so it loosens by turning clockwise.
7. Remove the Arbor Bolt, Outer Flange and Saw
Blade by pulling them straight off the Arbor.
8. Install a new Blade (sold separately) on the
Arbor. [H$$&>182-$&T/\ Be sure to match the
direction marked on the new blade with the
direction marked on the saw Blade Housing.
>182-$&T%&&N$:"W1<8&'()*$
9. Replace the Outer Flange and Arbor Bolt.
Tighten the Arbor Bolt securely using the
Wrench by turning it counterclockwise.
10. Rotate the Center Cover back into place
and tighten the Center Cover Fixing Bolt
using the Wrench by turning it clockwise.
11. Release the Locking Pin.
