Page 8 For technical questions, please call 1-800-444-3353. SKU 93213
ASSEMBLY
WARNING! Unplug the tool before changing
grinding wheels, or before making any
adjustments to the tool.
Installation
Install the Sharpener to a workbench 1.
before use.
FIGURE 1
1/4” Hole
with Bolt
Lock Wheel (18)
1. When installing the sharpener on a
workbench, make sure that the Lock
Wheel (18) is accessible, as shown in
the mounting picture in FIGURE 1.
Base (17)
FIGURE 2
2. Bolt (bolts not included) the unit directly
to the workbench through the two 1/4”
holes on the Base (17). The workbench
must have a solid surface capable of
supporting the weight of this product,
the workpiece and assorted tools. See
FIGURE 2.
To Next Page
