R410A50Hz Universal Outdoor Series TechnicalManual Outdoor unit
152
GD Chigo Heating & Ventilation Equipment Co., Ltd.
13.3 Terminal 1
13.4 Groove clamp 4# 1
13.5 Groove clamp 9# 1
13.6 Cover for E-parts 1
13.8
Fan motor capacitor
2
13.9
Contactor
1
13.10
Sequence protector
1
14
High-pressure valve assy
1
14.1
filter
1
14.2 High-pressure valve 1
14.3 Cut-off valve DN8 1
14.4 Refrigerate-capillary 1
15 Rear clapboard for valve 1
16 Rear clapboard for valve 1
17 Right clapboard 1
18
Right clapboard for valve
1
19
Suction pipe assy
1
21
Compressor
1
22
Chassis
1
23
Separating board
1
9.Troubleshooting
Fault display
