1.2 Attachments and Consumable Parts
1. Attachments check
The following attachments are contained. Check if these attachments are delivered normally.
Part names Q’ty Remarks
1. Chart 1 pad Chart No. EH-01001
2. Mounting bracket 2 pcs.
Used for mounting the instrument to a panel.
Hole profiles differ between right and left sides.
3. Wrench 1 Pc. Fasten mounting screws
4. Cassette ribbon 1 Pc. 6-color ink ribbon for analog and digital printing
5. Channel indicating card 1 sheet Inserted inside the door (For 6 points, 12 points, or 24 points)
6. Lubricating oil 1 bottle For lubricating the main shaft of printer
7. Terminal screw 5 pcs. M3.5 screws Auxiliary screws for input and alarm terminals
1 pad INE-271 (for instruments)
8. Instruction manual
(1 pad)
INE-272 (for communications interface)
Attached to the instrument with communications interface.
2. Ordering of consumables
Chart and cassette ribbon are consumables. For ordering them, please specify them, referring to the
following table.
Name Article name and specifications for ordering Handling unit
Chart Chart No. (Example EH-01001) 1 case (containing 15 pads)
Cassette ribbon 6-color cassette ribbon (For AH: No. 84-0055) 1 piece
1. Chart
2. Mountin
bracket
4. Cassette ribbon
5. Channel indicatin
card
6. Lubricating oil
3.Wrench
7. Terminal screw
