0-7
MAJOR FEATURES AND FUNCTIONS
This instrument can record temperature and other various industrial variables on a 180mm chart in 6 , 12
or 24 channels.
○
1
Trace printing by dots
○
2
Digital printing to print measured values and other data
1. Features
Major features are shown below.
･Universal input. A range can optionally be selected every channel out of 10 DC voltage ranges, 36
thermocouple ranges, and 11 resistance thermometer ranges.
･Universal power supply. The working voltage range is 100 to 24OVAC, 50/60Hz.
･Conforms to international safety standards. Conforms to CE marking or approved and UL and CSA (C-UL)
approved.
･The basic operation is done after programming range numbers and trace printing range.
･All operations can be done on the front keyboard without any need of drawing out the internal unit. The
internal unit cannot be drawn out.
2. Functions
Major functions are shown below.
Display functions
Printing functions
Multi-point
sequential
display
･Measured values are displayed sequentially every
channel.
･Chart speed and time are displayed.
･Six kinds of status are displayed.
･Alarm-on channel number are displayed.(Note)
Multi-point
simultaneous
display
･Simultaneous display of measured values in 6
channels or 12 channels (12-point selective display
for 24 channels)
･Three kinds of status are displayed.
･Operation display screen selection.
･Measured values flicker if alarm is on.(Note)
･Operation screens selectable
･Trace printing all channels by dots
･Fixed time printing (time line, time,
scale, engineering unit, tag)
･ Periodic data printing (Measured
values are digitally printed at preset
intervals)
･Digital data printing (Digital printing
of measured values on demand)
･Alarm printing (Note)
Note: Programming of alarms is necessary. Alarm output is only available by adding an option of [Alarm
output].
