CHINT NXBLE-63Y - Page 7

6
10
16, 20
25
32
40,50
63
1
1.5
2.5
4
6
10
16
Rated current In (A)
2
Copper wire cross-sectional area (mm )
Table 2 Copper wire cross-sectional area
04
5. Wiring: Suitable for copper wire . See Table 2 for wire connection
Note: Before powering on the product, check whether the wiring is correct and verify the flexibility of the
handle action.
2.5N·m
1
N
Test regularly
2
N
2
t
i
lt
ou
t
lift
N
N
N
2 N
1
S
25mm
2
L
11mm
S
16mm
2
