Outline and installation size of NXM-400
～
1600
3P 4P
Table 2 Outline and Installation Size of NXM-400～1600
Unit: mm
Size type
Size code
Product model
NXM-400
NXM-630
NXM-800
NXM-1000
NXM-1250
NXM-1600
Outline
size
C
150
160
170
175
E
92
91
100
120
E1
46
45
52
37.8
F
50
50
60
78
G
32.5
44.5
44.5
53
G1
11.5
15
15
15
J
25
25
25
25
Hmax
161
165
168
202
207
H1
108.5
114
118
153
158
H2
97.5
103.5
106
143
148
H3
40.5
43
42
57
65
H4
41.5
45
43
57
65
L
257
270
280
370
L1
225
235
243
342
M
104
104
106
92.5
W1
140
182
210
210
W2
185
240
280
280
W3
44
58
70
70
W4
88
116
140
140
W5
132
174
210
210
Installatio
n size
A
44
58
70
70
A1
88
116
140
140
B
194
200
243
314
φd
7
7.2
7.2
6
Undervoltage release
Undervoltage release
Partial view of wiring
