Chord DAVE Operating Instructions

Adjusting the volume
Press the Vol+ button on the centre control to increase the volume, press the Vol- button on the centre
control to decrease the volume.
Mute
Press the key to mute Dave.
To un-mute
Press the key again.
Standby:
Press the button. You do not have to flick the master switch on the rear of the device.
Please note that when switching the unit on from standby there will be a 20 second delay where
the display will show ‘Mute’. This is to allow the unit to program, and for the system to settle.
Setup Menu
Press the BAL+ / MENU key on the remote to enter the setup menu. The press the VOL+/VOL- to
select the option. Press Line+ / Line – to make changes.
- ! -8

Chord DAVE Specifications

Audio Specifications

frequency response	20Hz to 20kHz
THD + N	127.5dB
channel separation	>125dB @ 1KHz
dynamic range	127.5dB

Digital Inputs and Outputs

digital inputs	4 x 75Ω SP/DIF BNC Coax 44.1KHz - 384KHz
AES balanced XLR input	44.1KHz - 96KHz
plastic fibre optic inputs	2 x TOSlink 44KHz - 192KHz
USB input	44KHz - 768KHz PCM + DSD
analogue outputs	2 x RCA Phono, 2 x Balanced XLR
headphone output at 300 ohm	1% THD 6.8v RMS (154 mW)
headphone output at 33 ohm	1% THD 6.8v RMS (1.4W)

Power and Dimensions

power supply	90V AC - 250V AC auto switching 50 - 60HZ
dimensions	338 x 60 x 145mm (Width x Height x Depth)
weight	7Kg
