Chord DAVE Operating Instructions

Product Specification
FREQUENCY RESPONSE: 20Hz to 20kHz flat within +/-0.1dB (HF filter off)
THD + N: 127.5dB (AWT)
CHANNEL SEPARATION: >125dB @ 1KHz
DYNAMIC RANGE: 127.5dB (AWT)
DIGITAL INPUTS: 4 x 75Ω SP/DIF BNC Coax 44.1KHz - 384KHz
1 x AES Balanced XLR 44.1KHz - 96KHz
2 x Plastic fibre optic ( TOSlink ) 44KHz - 192KHz
1 x USB ( B type ) 44KHz - 768KHz PCM + DSD
ANALOGUE OUTPUTS: 2 x RCA Phono
2 x Balanced XLR
HEADPHONE OUTPUT: 1% THD 6.8v RMS with 300 ohm (154 mW)
1% THD 6.8v RMS with 33 ohm (1.4W)
PHASE SWITCH: 2 Settings Positive or Negative output phase
SAMPLE FREQUENCIES: 44.1Khz - 768Khz DSD64,128,256,512 native DSD +
DoP (input dependant)
OUTPUT IMPEDANCE: 0.0055ohm (short circuit protected) damping factor 145
POWER SUPPLY: 90V AC - 250V AC auto switching 50 - 60HZ
DIMENSIONS IN MM: 338 x 60 x 145mm (Width x Height x Depth)
WEIGHT: 7Kg
- ! -13

Chord DAVE Specifications

Audio Specifications

frequency response	20Hz to 20kHz
THD + N	127.5dB
channel separation	>125dB @ 1KHz
dynamic range	127.5dB

Digital Inputs and Outputs

digital inputs	4 x 75Ω SP/DIF BNC Coax 44.1KHz - 384KHz
AES balanced XLR input	44.1KHz - 96KHz
plastic fibre optic inputs	2 x TOSlink 44KHz - 192KHz
USB input	44KHz - 768KHz PCM + DSD
analogue outputs	2 x RCA Phono, 2 x Balanced XLR
headphone output at 300 ohm	1% THD 6.8v RMS (154 mW)
headphone output at 33 ohm	1% THD 6.8v RMS (1.4W)

Power and Dimensions

power supply	90V AC - 250V AC auto switching 50 - 60HZ
dimensions	338 x 60 x 145mm (Width x Height x Depth)
weight	7Kg
