Chord DAVE Operating Instructions

Manual Controls
Dave can be operated manually by the controls on the top of the unit, or it can be operated using the
supplied remote control. Using these controls you can select the digital input, adjust the volume level,
and make changes to the setup options.
The top control panel features 4 push buttons and a rotary volume control.
The volume control rotates left or right to decrease or increase the volume level. Pushing it down will
mute or unmute the output.
The left/right buttons select the digital input and this is displayed on the top right of the screen.
The up/down buttons select the setup options at the bottom of the screen. Once an option is highlighted
the left/right buttons will change the setting.
- ! -6

Chord DAVE Specifications

Audio Specifications

frequency response	20Hz to 20kHz
THD + N	127.5dB
channel separation	>125dB @ 1KHz
dynamic range	127.5dB

Digital Inputs and Outputs

digital inputs	4 x 75Ω SP/DIF BNC Coax 44.1KHz - 384KHz
AES balanced XLR input	44.1KHz - 96KHz
plastic fibre optic inputs	2 x TOSlink 44KHz - 192KHz
USB input	44KHz - 768KHz PCM + DSD
analogue outputs	2 x RCA Phono, 2 x Balanced XLR
headphone output at 300 ohm	1% THD 6.8v RMS (154 mW)
headphone output at 33 ohm	1% THD 6.8v RMS (1.4W)

Power and Dimensions

power supply	90V AC - 250V AC auto switching 50 - 60HZ
dimensions	338 x 60 x 145mm (Width x Height x Depth)
weight	7Kg
