Chord Hugo 2 User Manual

Chord Electronics
Hugo 2 | User manual
12
8.3 Crossfeed
The three-stage crossfeed function emulates a speaker listening environment by blending the left and
right channels by 3 dB, 6 dB and 9 dB based on setting. Please reference the graph below.
3 dB 6 dB 9 dB O
8.4 Brightness
The Hugo 2 has two user adjustable brightness settings for light or dark environments. To adjust, press
the ‘dim’ button on the accompanying remote control. Alternatively, press both the ‘Filter’ and ‘X-PHD’
buttons simultaneously

Chord Hugo 2 Specifications

General

Product color	Black
Frequency range	20 - 20000 Hz
Output impedance	0.025 Ω
Channel separation	135 dB
Peak power per channel	- W
Signal-to-Noise Ratio (SNR)	126 dB
Total Harmonic Distortion (THD)	0.0001 %
Battery life	7 h
Charging time	4 h
Number of batteries supported	2
Headphone connectivity	3.5mm
Cables included	Micro-USB

Weight and Dimensions

Depth	130 mm
Width	100 mm
Height	21 mm
Weight	450 g
