Chord Hugo M User Manual

will only experience a maximum upsampling of 384kHz. You no longer require your source to be connected to your
DAC.
Connecting M Scaler to a third-party DAC
Connecting M Scaler to a third-party DAC without a supported dual data mode (x2 parallel BNC inputs) will yield
maximum upsampling of 384kHz. We recommend connecting M Scaler to your DAC via BNC/ S/ PDIF for the
maximum upsampling of 384kHz in this configuration. Connect any output of M Scaler to the input of your DAC. You
no longer require your source to be connected to your DAC.
Connecting the power supply to M Scaler
Connect only the supplied power supply to the DC 15V input of M Scaler. Once connected, M Scaler will
automatically power on. M Scaler does not have a power button and will remain on until the power supply is
disconnected.
Selecting your input
Press the INPUT button to select the source you require. The colour changes depending on input selected, see
diagram below. If you are using dual data, when you select BNC 1 the M Scaler will automatically switch on both
outputs to dual data mode.

Chord Hugo M Specifications

General

Brand	Chord
Model	Hugo M
Category	Media Converter
Language	English
