Chore-Time Chore-Tronics - Introduction to the Control

Load Cell Indicator Overview
MT2316A
3
The Chore-Tronics Load Cell Indicator is used to indicate the amount of weight in a maximum of two
different feed bins that are setting on two different sets of loadcells.
facility.
Description of Control Front Panel
Viewing Screen
The viewing screen has a display which has 4 lines, each containing 20 characters. This is the area that will
display the requested information when a subject button is pressed. The viewing screen always remains lit.
Normally the Current Weight screen shows (Figure 2).
Overview
Introduction to the Control
Item Description
1 Navigation Buttons
2 Viewing Screen
3 Edit Buttons
4 Subject Buttons
Figure 1. Introduction to Control
4
1
2
3
Figure 2. Current Weight Screen.
Silo Bin 1 123456
Silo Bin 2 123456
CHECK ALARMS
06 Sep 2007 10:03a
