Load Cell Indicator Introduction to the Control
MT2316A
5
How to Maneuver in the Viewing Screen
•The procedures below give a brief overview on the use of the Navigation Buttons and the Edit Buttons.
•Screen 1, "Setup" is used for this example.
Using the Navigation Buttons
1. Press BUTTON 1. Figure 4 appears in the display.
2. Press the DOWN ARROW once.
The view shown on the screen will scroll down one line as shown in Figure 5. If you push the UP ARROW
once, the text scrolls back to where it was.
3. The left and right arrow keys are used during the Edit Mode.
Figure 4. Navigation Buttons.
Silo Bin 1 123456
Silo Bin 2 123456
CHECK ALARMS
06 Sep 2007 10:03a
Figure 5. Press Down Arrow.
Silo Bin 2 123456
CHECK ALARMS
06 Sep 2007 10:03a
To Next Page
