Systems
Chris-Craft 3–47
STBD SHUTDOWN WHITE/GREEN
STBD ENGINE RED/VIOLET
STBD ENGINE TEMPERATURE TAN
STBD ENGINE ALARM TAN/BLUE
STBD ENGINE TACHOMETER GRAY
STBD ENGINE OIL PRESSURE LIGHT BLUE
STBD ENGINE TRIM LEVEL BROWN/WHITE
STBD ENGINE IGNITION VIOLET
STBD ENGINE STARTER YELLOW/RED
GENERATOR STOP POWER RED/WHITE
GENERATOR STOP WHITE/RED
GENERATOR POWER RED/VIOLET
GENERATOR PRE-HEAT WHITE
GENERATOR START YELLOW/RED
PORT PARALLEL START RED
STBD PARALLEL START RED
BOW THRUSTER POWER RED
BOW THRUSTER BATTERY RED
BOW THRUSTER LEFT WHITE/RED
BOW THRUSTER RIGHT WHITE/GREEN
PORT SHUTDOWN PWR RED/WHITE
PORT SHUTDOWN WHITE/RED
STBD SHUTDOWN PWR GREEN
STBD SHUTDOWN WHITE/GREEN
HELM POWER RED
MAN BILGE SWITCH POWER RED
HELM SWITCH POWER RED
GENERATOR STARTER RED
GENERATOR BATTERY RED
ELECTRONICS POWER RED
SHIP’S SERVICE RED
HATCH SOLENOID RED
WINDLASS RED
WINDLASS CONTROL UP RED/BLUE
WINDLASS CONTROL DOWN RED/GREEN
Table 3-4. Engine/Battery Wire Codes (Continued)
Function Wire Color
