Chroma 62000L Series User Manual

General Information
1-9
<10ms (when the trip voltage is less than
2V)
OCP Activation Time
<10ms
AC Input Operating Voltage Range
1φ 100~120Vac ± 10% V
LN
or 1φ
220~240Vac ± 10% V
LN
, 47~63 Hz
Operating Temperature
0℃ to 40℃
Operating Humidity
Maximum relative humidity 80% for
temperature up to 35℃
Storage Temperature
- 40℃ to 70℃
Operating Altitude
Up to 2000 M
Interfaces
USB & GPIB standard
Dimension (H x W x D)
88.6 x 214.6 x 280.7 mm / 3.49 x 8.45 x
11.05 inch
Weight
< 2.5 kg / 5.5 lbs
Note
1. Change in output voltage or current for any load change within ratings.
2. For 0-100% load step with nominal line voltage.
3. with outputs ungrounded, or either output terminal grounded, 20 Hz to 20 MHz.
4. Maximum change in output/read-back per °C after a 30-minute warm-up.
5. The accuracy specifications are gained under 1-hour warm-up condition and
the calibration at 25°C.
6. Maximum time required for output voltage to settle within 1% of its total
excursion (for resistive load). Excludes command processing time.
1.8 Contents
Make sure that you have received the following items in the shipment of your power supply. If
anything is missing, damaged, or malfunctioning, contact your distributor.
 One 62010L-36-7 or 62015L-60-6 (88.6[H] x 214.6 [W] x 280.7 [D] mm, < 2.5 Kgs)
 USB & GPIB interface card (USB cord included)
 Front/rear bumper
 One CD (including this electronic User's Manual)
1.9 Dimension
1. The dimension without the front & rear bumpers, and the terminals is (LxWxD - 214.6 x
88.6 x 280.7 mm).
2. The dimension with the front & rear bumpers, but without the terminals is (LxWxD – 226.8
x 107 x 305 mm).
