Digital Power Meter 66200 Series User’s Manual
[ CALCulate : ] COMParator : LIMit : THDV 66202
Description:
This command sets upper and lower boundaries of total harmonic distortion of
voltage in GONG mode.
Setting Syntax:
COMParator:LIMit:THDV<space><NR2>,<NR2><PMT>
Setting Parameters: <NR2>, 0.00 ~ 99.99
Query Syntax: COMParator:LIMit:THDV?<PMT>
Response Parameters: <NR2> , 0.00 ~ 99.99
Header on: :COMPARATOR:LIMIT:THDV<space><NR2>,<NR2><RMT>
Header off: <NR2>,<NR2><RMT>
Separator 0: <NR2>,<NR2><RMT>
Separator 1: <NR2>;<NR2><RMT>
Example: none
[ CALCulate : ] COMParator : LIMit : I 66201 | 66202
Description: This command sets upper and lower boundaries of current (r.m.s.) in GONG
mode.
Setting Syntax:
COMParator:LIMit:I<space><NR2>,<NR2><PMT>
Setting Parameters: <NR2>,
66201: 0.000 ~ 9.999
66202: High shunt: 0.00 ~ 99.99
Low shunt: 0.000 ~ 9.999
Query Syntax: COMParator:LIMit:I?<PMT>
Response Parameters: <NR2>,
66201: 0.000 ~ 9.999
66202: High shunt: 0.00 ~ 99.99
Low shunt: 0.000 ~ 9.999
Header on: :COMPARATOR:LIMIT:I<space><NR2>,<NR2><RMT>
Header off: <NR2>,<NR2><RMT>
Separator 0: <NR2>,<NR2><RMT>
Separator 1: <NR2>;<NR2><RMT>
Example: none
[ CALCulate : ] COMParator : LIMit : IPK+ 66201 | 66202
Description: This command sets upper and lower boundaries of positive peak current in
GONG mode.
Setting Syntax:
COMParator:LIMit:IPK+<space><NR2>,<NR2><PMT>
Setting Parameters: <NR2>,
66201: 0.000 ~ 9.999
66202: High shunt: 0.00 ~ 99.99
Low shunt: 0.000 ~ 9.999
Query Syntax: COMParator:LIMit:IPK+?<PMT>
Response Parameters: <NR2>,
66201: 0.000 ~ 9.999
66202: High shunt: 0.00 ~ 99.99
Low shunt: 0.000 ~ 9.999
Header on: :COMPARATOR:LIMIT:IPK+<space><NR2>,<NR2><RMT>
Header off: <NR2>,<NR2><RMT>
Separator 0: <NR2>,<NR2><RMT>
5-28
