Introduction
The CHRYSLER13 firmware for Directed Digital Solutions is a complete solution for remote start, security (if
applicable), bypass interface, and convenience needs compatible with specific Jeep vehicles.
Warning! This module can only be programmed via the web tool, which can be found on
www.directechs.com or using the Directechs Mobile application for smartphones. Features and functions will
become accessible when you connect the module using the XKLoader.
Pre-installation and application warnings
Firmware notes: This section highlights important information for this specific firmware and will assist in
pricing accordingly, as well as bringing awareness to any operational or vehicle limitations.
T-Harness
compatible
Keys required for
programming
1
Keys required for
operation
0
Important: The firmware does not control the OEM alarm. Remove the battery int the OEM remote to prevent the vehicle
from arming. The vehicle's OEM alarm will no longer be functional. The installation of a hybrid system (remote starter and
alarm combo) is highly recommended to preserve vehicle security, except when door lock control is not needed.
No Takeover/Pit Stop Mode is available.
Key2GO is mandatory to control the immobilizer override in this firmware.
Unless specified otherwise, all connectors are displayed from the wire side, with the exception of the OBDII diagnostic
connector.
Refer to the "Vehicle wiring reference chart" following each installation type.
General notes: This section highlights important information for this specific firmware.
[1] The installation of an aftermarket hood pin is only required on vehicles that are not eqquipped with a factory hood pin.
[2] The siren is only available with the Directed Digital remote start and security system.
Additional parts required (maximum required):
0 x 1A Diodes
86 85
30
87a
87
0 x Relay
1 x 2.5 kΩ Resistor
1 x 500 Ω Resistor
0 x Fuse
