Chrysler Directed - Installation (wiring diagrams & vehicle wiring reference charts)

8
Directed Digital Solutions CHRYSLER13
© 2016-07-12 Directed. All rights reserved.
Installation (wiring diagrams & vehicle wiring reference charts)
Refer to "Pre-installation and application warnings" on page 4 and "Vehicle wiring reference chart" on page 9 for important information on this installation.
86 85
30
87a
87
12: Brown: (-) Lock Output
3: Brown/Red: (+) 12V
4: Yellow/Red: (+) Accessory Output
6: Yellow: (-) Lock Input
9: Black: (-) Ground
10: Red: (+) 12V
Green 60-pin connector
(at BCM, dash fusebox)
Black 10-pin connector
(at Headlight Switch)
Gray 2-pin
connector
(at BCM,
dash fusebox)
HS CAN Low: Tan : 4
HS CAN High: Tan/Black: 5
MS CAN High: Orange/Green: 7
MS CAN Low: Orange/Brown: 8
(+) Ignition Output: White/Red: 12
(-) Parking Lights Output: Lt. Blue/Black: 13
(+) Starter Output: Green/Red: 14
(-) Unlock Output: Dk. Blue: 7
Siren
The Remote Start
Safety Override
Switch MUST be in
the ON position.
Remote Start Safety
Override Switch
Hood Pin
(-) Hood Input: Gray: 3
(+) Siren Output: Brown: 17
B
A
1 2 3 4 5
6 7 8 9 10
1
16
31
46
15
30
45
60
(+) Accessory:
Gray, pin 1
(+) Ignition:
Blue, pin 2
(MUX) Parking Lights:
White/Orange, pin 1
Black 2-pin connector
(at Ignition Switch)
1
2
Black 3-pin connector
(at Ignition Switch)
1
2
(+) Starter:
Brown, pin 3
(MUX) Door Locks:
White/Blue, pin 14
3
OBDII
Diagnostic
Connector
C-CAN Low:
Brown, pin 14
C-CAN High:
Lt. Green, pin 6
B-CAN Low:
White, pin 11
B-CAN High:
Blue, pin 3
16
8
9
1
(+) 12V:
Red, pin A
Resistor
2.5 kΩ
Resistor
370 Ω
CUT
Resistor
500 Ω
Fuse 5A
