Analog harness (H3), 18-pin white connector
Conn./Pin Color Description
H3/1 Lt. Blue/Red No Connection
H3/2 Black/White (-) Parking Brake Input (Manual Transmission)
2
H3/3 Gray (-) Hood Input
2
H3/4 N/A No Connection
H3/5 Gray/Black (+) Glow Plug Input
2
H3/6 Violet/White (AC) Tach Input
2
H3/7 Dark Blue (-) Unlock Output
1
H3/8 Brown/Black (-) Horn
1
H3/9 Red/White No Connection
1
H3/10 White/Green (-) Door Input
2
H3/11 Yellow/Green (+) Door Input
2
H3/12 Blue/Red No Connection
H3/13 Light Blue (-) Trunk Trigger Input
2
H3/14 Pink/Yellow (-) Activation (Start Trigger) Input
H3/15 Dark Green No Connection
1
H3/16 Brown/White (+) Brake Input
2
H3/17 Brown (+) Siren Output
1
H3/18 Blue/White (-) Ground When Running (Status) Output
1
MC501 harness (H4), 8 thick-gauge wires (optional)
Conn./Pin Color Description
H4/1 Pink/White No Connection
H4/2 Red/White No Connection
H4/3 Pink No Connection
H4/4 Red No Connection
H4/5 Orange No Connection
H4/6 Red No Connection
H4/7 Green No Connection
H4/8 Violet No Connection
1. If these outputs are not used by the firmware, they can be configured by the installer when the module is flashed. Note that they are low current and a relay
may be necessary.
2. These connections are only required if the corresponding statuses are not supported by the firmware. See "Vehicle application guide" on page 5 for a
list of compatible features.
