Wiring connections
The wiring connections listed below are specific to this firmware.
Main power harness (H1), 12-pin thick gauge connector
Conn./Pin Color Description
H1/1
White Relay 3 COM – No Connection
1
H1/2
White/Brown Relay 3 N.O. – No Connection
1
H1/3 Brown/Red Relay 2 N.O.– (+) 12 Volt (Battery)
H1/4 Yellow/Red Relay 2 COM – (+) Accessory Output
H1/5
Orange/Red Relay 2 N.C. – No Connection
H1/6 Yellow Relay 1 COM – (-) Lock Input
1
H1/7
White Relay 3 COM – No Connection
1
H1/8 White/Brown Relay 3 N.O. – No Connection
1
H1/9 Black (-) Ground
H1/10 Red (+) 12 Volt (Battery)
H1/11
Orange/Yellow Relay 1 N.C. – No Connection
1
H1/12 Brown Relay 1 N.O. – (-) Lock Output
Auxiliary output harness (H2), 16-pin black connector
Conn./Pin Color Description
H2/1 Violet/Brown No Connection
H2/2
Yellow/Black No Connection
H2/3
Orange/Black No Connection
H2/4 Tan HS CAN Low
H2/5 Tan/Black HS CAN High
H2/6 Light Green No Connection
H2/7 Orange/Green MS CAN High
H2/8 Orange/Brown MS CAN Low
H2/9 Violet/Green No Connection
H2/10 Green/Black No Connection
2
H2/11 White/Violet No Connection
2
H2/12 White/Red (+) Ignition Output
2
H2/13 Lt. Blue/Black (-) Parking Lights Output
2
H2/14
Green/Red (+) Starter Output
2
H2/15 N/A No Connection
H2/16 Violet/Yellow No Connection
1. If these outputs are not used by the firmware, they can be configured by the installer when the module is flashed.
2. If these outputs are not used by the firmware, they can be configured by the installer when the module is flashed. Note that they are low current and a relay
may be necessary.
