SERVICING AND MAINTENANCE 375
F49 25 Amp Clear –
RR Sliding Door Module-LT — If
Equipped
F50 25 Amp Clear – RR Door Module-RT — If Equipped
F51 30 Amp Pink – Front Wiper
F52 30 Amp Pink – Brake Vacuum Pump
F53 – – Not Used
F54 40 Amp Green – ESP-ECU And Valves
F55A – 15 Amp Blue
Radio Frequency HUB/ Keyless
Ignition System (KIN) / (Electronic
Steering Lock-BUX ONLY) — If
Equipped
F55B – 15 Amp Blue
DVD / Video Routing Module (VRM)
— If Equipped
F56A – 10 Amp Red
Front and Rear HVAC Control
Module / Occupant Classification
Module (OCM)/Electronic Steering
Lock (ESL)
F56B – 10 Amp Red ESP/ESC
F57 – – Not Used
F58 – 10 Amp Red
Drive Train Control Mod / Power
Transfer Unit — If Equipped
F59 30 Amp Pink –
Trailer Tow Receptacle — If
Equipped
Cavity Cartridge Fuse Blade Fuse Description
