280 SERVICING AND MAINTENANCE
F72 – 10 Amp Red Heated Mirror *
F73 30 Amp Pink – Rear Defroster
F74 20 Amp Blue – Trailer Tow Backup Lights*
F75 – 5 Amp Tan Overhead Console / RR Center Stack
F76 – 20 Amp Yellow Uconnect / Center Display / Telematics
F77 – 10 Amp Red
RR Entertainment / Media HUB / USB(S) /
Rain Sensor / Sunroof / RR View Mirror/
Overhead DVD Player / INT Monitoring
Camera / Wireless Charging Pad
F78 – 15 Amp Blue TCM (ZF) / E-Shifter / Cluster
F79 – 10 Amp Red ICS / HVAC / SCCM/ EPB SW
F80 – – Not Populated
F81 – – Not Populated
F82 – – Not Populated
F83
20 Amp Blue – TT Park Lights *
30 Amp Pink – Headlamp Washer Pump *
F84 30 Amp Pink – Drive Train Control MOD *
F85 – 20 Amp Yellow Cigar Lighter
F86 – – Not Populated
F87 – – Not Populated
F88 – 20 Amp Yellow Front Heated Seats *
F89 – 20 Amp Yellow Rear Heated Seats *
F90 – – Not Populated
Cavity Cartridge Fuse Blade Fuse Description
*If Equipped
