INSTRUMENT CLUSTER DISPLAY
MENU ITEMS
The instrument cluster display can be used to view the
main menu items for several features. Use the up
and down arrow buttons to scroll through the
driver interactive display menu options until the desired
menu is reached
page 60.
NOTE:
The instrument cluster display menu items display in
the center of the instrument cluster. Menu items may
vary depending on your vehicle features.
Speedometer
Push and release the up or down arrow button
until Speedometer is highlighted in the instrument clus-
ter display. Push and release the OK button to toggle
between MPH and km/h.
Vehicle Info
Push and release the up or down arrow button
until Vehicle Info is highlighted in the instrument cluster
display. Push the left
or right arrow button to
scroll through the following information submenus:
Tire Pressure
If tire pressure is OK for all tires, a vehicle icon is dis-
played with tire pressure values in each corner of the
icon.
If one or more tires have low pressure, “Inflate Tire To
XX” is displayed with the vehicle icon, and the tire pres-
sure values in each corner of the icon with the pressure
value of the low tire displayed in a different color than
the other tire pressure value.
If the Tire Pressure system requires service, “Service
Tire Pressure System” is displayed.
Tire PSI is an information only function and cannot be
reset
page 127.
Coolant Temp
Displays the actual coolant temperature.
Transmission Temp
Displays the actual transmission temperature.
Oil Temp
Displays the actual oil temperature.
Oil Pressure
Displays the actual oil pressure.
Oil Life
Displays the remaining engine oil life as a percentage.
To reset the Oil Life, you must hold the OK button. The
“Hold OK to Reset” instruction will be displayed at all
times, but the following conditions will need to be met
in order to reset Oil Life:
•
The ignition must be in the ON/RUN position
If the conditions are met, holding the OK button will
reset the gauge and the numeric display will return to
100%.
If the conditions are not met, a pop-up message will
display for five seconds, describing the required condi-
tions, and then the Oil Life screen will reappear.
Battery Voltage
Displays the actual battery voltage.
Engine Hours — If Equipped
Displays the number of hours of engine operation.
Driver Assist — If Equipped
Push and release the up or down arrow button
until the Driver Assist display icon is highlighted in the
instrument cluster display
page 83.
Fuel Economy
Push and release the up or down arrow button
until the Fuel Economy Menu item is highlighted in the
instrument cluster display. The Fuel Economy Menu will
display the following:
•
Two submenu pages that can be toggled between
using the left
and right arrow buttons; one
with Current Value displayed and one without the
Current Value displayed:
○ Average Fuel Economy (MPG, L/100 km, or km/L)
○ Range To Empty (miles or km)
○ Current Fuel Economy (MPG, L/100 km, or km/L)
○ The Max and Min values will correspond to the
particular engine requirements
•
Hold OK to reset average fuel economy information.
Trip Info
Push and release the up
or down arrow button
until the Trip Menu item is highlighted in the instrument
cluster display. Push the left
or right arrow but-
ton to scroll through the Trip A and Trip B submenus.
The Trip information will display the following:
•
Distance
•
Average Fuel Economy
•
Elapsed Time
Hold the OK button to reset feature information.
Stop / Start – If Equipped
Push and release the up or down arrow button
until the Stop/Start menu title is displayed in the instru-
ment cluster display.
62 GETTING TO KNOW YOUR INSTRUMENT PANEL
