WARNING ALERTS
Rear Distance
(inches/cm)
Greater than
79 inches
(200 cm)
79-59 inches
(200-150 cm)
59-47 inches
(150-120 cm)
47-39 inches
(120-100 cm)
39-25 inches
(100-65 cm)
25-12 inches
(65-30 cm)
Less than
12 inches (30 cm)
Arcs — Left None None None None None 2nd Flashing 1st Flashing
Arcs — Center None 6th Solid 5th Solid 4th Solid 3rd Flashing 2nd Flashing 1st Flashing
Arcs — Right None None None None None 2nd Flashing 1st Flashing
Audible Alert
Chime
None
Single 1/2
Second Tone
(for rear center
only)
Slow
(for rear center only)
Slow
(for rear center
only)
Fast
(for rear center
only)
Fast Continuous
Radio Volume
Reduced
No Yes Yes Yes Yes Yes Yes
NOTE:
ParkSense will reduce the volume of the radio, if on, when the system is sounding an audio tone.
ENABLING AND DISABLING
PARKSENSE
ParkSense can be enabled and disabled
with the ParkSense switch, located on the
switch panel below the Uconnect display.
When the ParkSense switch is pushed to
disable the system, the instrument cluster will display
the “ParkSense Off” message for approximately five
seconds. When the gear selector is moved to REVERSE
and the system is disabled, the instrument cluster dis-
play will show the “ParkSense Off” message for as long
as the vehicle is in REVERSE.
The ParkSense switch LED will be on when ParkSense
is disabled or requires service. The ParkSense switch
LED will be off when the system is enabled. If the
ParkSense switch is pushed, and requires service, the
ParkSense switch LED will blink momentarily, and then
the LED will be on.
SERVICE THE PARKSENSE REAR
PARK ASSIST SYSTEM
During vehicle start up, when the ParkSense Rear Park
Assist system has detected a faulted condition, the
instrument cluster will actuate a single chime, once per
ignition cycle, and it will display the “ParkSense Unavail-
able Wipe Rear Sensor” or the “ParkSense Unavailable
Service Required”. When the gear selector is moved to
REVERSE and the system has detected a faulted condi-
tion, the instrument cluster display
page 60 will
show the "ParkSense Unavailable Wipe Rear Sensor" or
"ParkSense Unavailable Service Required" message for
five seconds while the vehicle is in REVERSE. The
vehicle graphic will remain displayed for as long as the
vehicle is in REVERSE.
If “ParkSense Unavailable Wipe Rear Sensor” appears
in the instrument cluster display, make sure the outer
surface and the underside of the rear fascia/bumper is
clean and clear of snow, ice, mud, dirt, or other obstruc-
tions and then cycle the ignition. If the message contin-
ues to appear, see an authorized dealer.
If “ParkSense Unavailable Service Required” appears in
the instrument cluster display, see an authorized
dealer.
STARTING AND OPERATING 87
