3 - ELECTRICAL SPECIFICATIONS
Master controller BOX ELEC Eco +:
Protection: IP 55
Food: Self- powered RS485 son 4 bus (12V)
Slave box BOX ELEC Eco +:
Protection: IP 65
Food: TRI 400V + Neutral - 50 Hz
4 - DIMENSIONS OF THE COMPONENTS
Master controller
Overall dimensions
(without cable glands)
Center distance of fastening
Slave box BOX ELEC Eco +
Overall dimensions
(without the connection cabling)
Center distance of fastening
(With mounting brackets supplied dand the slave
box x 4
BOX ELEC Eco+ EN-20
