BORNIER X2
Bornes 1 - 2 : enlever le pont (CA machine) entre les bornes
1 et 2 et raccorder un contact (contact libre de toute polarité et
de bonne qualité).
Contact ouvert --> groupe a l’arrêt
Contact fermé --> groupe autorisé a fonctionner
Bornes 3 - 4 : enlever le pont (CA pompe) entre les bornes 3
et 4 et raccorder un contact (contact libre de toute polarité et
de bonne qualité).
Contact ouvert --> pompe a l’arrêt
Contact fermé --> pompe autorisé a fonctionner
Bornes 5 - 6 : raccorder un contact entre les bornes 5 et
6 (contact libre de toute polarité et de bonne qualité).
Contact ouvert --> consigne 1
Contact fermé --> consigne 2
Bornes 7 - 8 : enlever le pont (Arrêt d’urgence) entre les
bornes 7 et 8 et raccorder un contact (contact libre de toute
polarité et de bonne qualité).
Contact ouvert --> groupe a l’arrêt
Contact fermé --> groupe autorisé a fonctionner
TERMINAL BLOCK X2
Terminals 1 - 2 : remove connection between 1 and 2 and wire
a free voltage contact
Contact is opened --> unit can not run
Contact is closed --> unit can run
Terminals 3 - 4 : remove the connection between 3 and 4 and
wire a free voltage contact.
Contact is opened --> unit can not run
Contac is closed --> pump can run
Terminals 5 - 6 : wire a free voltage contact between
5 and 6
Contact is opened --> set point 1
Contac is closed --> set point 2
Terminals 7 - 8 : remove the connection between 7 and 8 and
wire a free voltage contact.
Contact is opened --> unit can not run
Contact is closed --> unit can run
X2
1
6-20
6-14
6-14
6-15
6-15
6-17
6-17
6-18
6-18
7-16
7-16
6-20
6-20
6-21
6-20
6-20
6-21
6-22
6-20
6-23
6-20
6-22
6-21
6-21
5-11
5-11
5-11
5-12
5-12
6-12
6-22
6-23
6-23
6-23
6-24
7-13
7-14
7-14
2
3
4
5
6
7
8
9
10
11
12
13
14
25
26
27
28
29
30
31
32
33
34
35
36
37
38
Raccordements usine
Factory wirings
Raccordements client
Customer wiringss
Commande d’automaticité
Unit external ON/OFF contact
Commande pompe eau
Water pumps external ON/OFF contact
Sélection consigne 1/consigne 2
Set point 1/set point 2 selection
Arrêt d’urgence
Emergency stop
Défaut général (client)
General fault (customer)
Délestage compresseur 1 ou 2
Load shedding compressor 1 or 2
Délestage compresseur 3
Load shedding compressor 3
Commande à distance 4 - 20mA
Remote control 4 - 20mA
Contact de signalisation défaut
General fault contact
Défaut groupe circuit 1
Circuit 1 fault
Défaut groupe circuit 2
Circuit 2 fault
Défaut groupe circuit 3
Circuit 3 fault
Contact libre de toute polarité
Free voltage contacts
Raccordements électriques client
Customer electrical wirings
