Cibo Vanity Cabinet - Door Hinge Alignment Adjustment

6
2 There are three primary screws that
can be adjusted to align the door.
2
b This screw moves the hinge left or right.
Clockwise direction = moves the hinge left
Anticlockwise direction = moves the hinge right.
(The opposite occurs when the hinge is tted the other way around)
b
a This screw moves the hinge up or down.
Clockwise direction = raises the hinge
Anticlockwise direction = lowers the hinge
(The opposite occurs when the hinge is tted the other way around)
a
c This screw moves the hinge in or out.
Clockwise direction = moves the hinge towards the vanity
Anticlockwise direction = moves the hinge away from the vanity
c
Vanity Unit Type A
Door/Hinge Adjustment (responsibility of the installer)
1 Remove the hinge cover
plate (if applicable).
1
Locate the hinges of the
door to be adjusted. It may
be necessary to adjust all
hinges in order to achieve
correct alignment.
