Cima PLUS - Hydraulic Circuit Components

Plus 42 - 45 - 50 - 55
09-2008
14
4.3 - HYDRAULIC CIRCUIT COMPONENTS
LEGEND:
P - E = elements of the circuit
T = piping
* = For versions in which this is envisaged
Hydraulic connections diagram 00243
T9
b
c
a
P2
P4
P6
P12
P8
BS
BP
P7
P5
P9
P11
d
b
a
c
T6
T1
T2
T5
TR
T4
E9
E10
T4
T5
®
+
-
ON
ON
OFF
OFF
Spin
Remote Control
HO
2
Press.
Pump
P1
*
*
P13
P14
*
*
MIXER
PIPE
DUST
PRODUCTS
MIXER
TANK
HYDRAULIC
AGITATION
FILTER
DELIVERY
PIPE
DELIVERY
PIPE
SUCTION
PIPE
FILLER PIPE
(ACCESSORY)
TO THE
DISTRIBUTION
HEAD
PUMP
RETURN TO
TANK PIPE
09-2008
Plus 42 - 45 - 50 - 55
55
CHECK
Fan belt-tensioner spring: CHECK LENGTH 9-12cm.. YES YES ** ** **
Pump belt-tensioner spring: CHECK LENGTH 4-5cm. . YES YES ** ** **
Fan shaft support: CHECK OIL LEVEL YES YES ** ** 8 h
Fan shaft support: REPLACE OIL LEVEL ** ** ** YES
1
year
Ta nk :
CHECK SECURING TIE ROD AND ANCHORING BRACKET
YES YES ** ** **
Fan belt-tensioner support: GREASING ** ** ** YES
200
h
Free wheel: GREASING ** ** ** YES
200
h
Filter: CHECK CLEANING YES YES YES YES **
Fittings and piping: CHECK GOOD CONDITION YES YES ** YES **
Clamps and fittings:
CHECK FOR INTEGRITY, PERFECT SEALING AND TIGHTENING
YES YES ** ** **
Wheels: CHECK THE SCREW NUTS TIGHTENING AND TYRES
PRESSURE
YES YES * * YES * *
Wheel hubs' fastening screws: CHECK THE TIGHTENING YES YES ** YES **
Hydraulic circuit and tank: COMPLETELY DRAIN AND WASH ** ** YES YES **
Sprayer: EXTERIOR WASHING ** ** YES YES **
Sprayer: STORAGE ** ** ** YES **
13.10 - TABLE OF MAINTENANCE OPERATIONS
UMAPT12
SEASON START TREATMENTS BEFORE EVERY TRATMENTS
END OF EVERY TREATMENTS
SEASON-END TREATMENTS
RECOMMENDED FREQUENCY
