Plus 42 - 45 - 50 - 55
09-2008
26
Tank capacities (litres)
300 400 600
Plus
42
Total width (mm)
960 1120 -
Total height (mm)
1160 1180 -
Length (mm)
1380 1380 -
Weight, empty (kg)
195 200 -
Weight, full load (kg)
513 618
Plus
45
Total width (mm)
960 1120 -
Total height (mm)
1160 1180 -
Length (mm)
1380 1380 -
Weight, empty (kg)
202 207 -
Weight, full load (kg)
520 625
Plus
50
Total width (mm)
960 1120 1450
Total height (mm)
1160 1180 1230
Length (mm)
1450 1450 1450
Weight, empty (kg)
225 230 244
Weight, full load (kg)
543 648 862
Plus
55
55S
55E
Total width (mm)
- 1120 1450
Total height (mm)
-11801230
Length (mm)
- 1480 1480
Weight, empty (kg)
-236250
Weight, full load (kg)
-654868
UMAPT02
4.4 - TECHNICAL DATA
4.4.1 - Machines dimensions and weights
- with protection ring
- without distribution device
- without accessories
4.4.2 - Centrifugal pump CD32
Model C.I.M.A. CD32 - Grid/filter on suction - Drain plug - Filler for the connection of the filling pipe, with
plug with chain.
Activated with trapezoid belt driven by the pulley mounted on the fan shaft.
Technical data printed on the body of the pump.
—Speed .................................................................................................................. 4000 RPM Plus42
—Flow rate ....................................................................................................... 120 litres/min. Plus42
—Speed ................................................................................................. 4250 RPM Plus 45-50-55S-E
—Flow rate ..................................................................................... 140 litres/min. Plus 45-50-55S-E
—Maximum pressure ....................................................................................................... 4.5 Kg/cm 2
—Power absorbed .................................................................................................................. kW 2.5
The performance specified is obtained with the drive outlet (PTO) at 540 RPM
For a good result of the treatments this condition MUST ALWAYS BE
OBSERVED during the machine’s operation. Utilisation is permitted with
speed rates ranging between 500 and 620 RPM
09-2008
Plus 42 - 45 - 50 - 55
43
g. Wash and rinse the just emptied product containers with clean water – collect the washing water
and pour it in the tank before carrying out the filling – place the empty packaging in the specific
container or in the collection area.
h. Wash the equipment and tools utilised in the preparation and place them in the chemical products
storage area.
i. Always leave the area assigned to the loading and preparation of the mixtures in such condition
as to avoid any possibility of contamination to persons or animals or of pollution to the environment.
l. If necessary, mark the field or the area of machine passes in order to provide a guide for the
treatment and avoid missing or double-treating coverage areas.
• AT THE END OF THE OPERATIONS NECESSARY FOR CARRYING OUT THE INTERVENTION,
THE LOCATION-STORAGE AREAS MUST BE LEFT IN THE CONDITION REQUIRED FOR THE
CARRYING OUT OF THEIR PREVENTION AND PROTECTION FUNCTIONS.
• BEFORE STARTING THE TRACTOR, KEEP AWAY PERSONS OR ANIMALS AND NEVER
LEAVE IT UNATTENDED DURING THE PREPARATION OPERATION.
10.3 - THE TREATMENT
IT IS ADVISABLE TO BEGIN TREATMENT AT THE HEADLANDS..
WHEN THE TREATMENT IS OVER, OR IF THE SAME HAS TO BE TEMPORARILY INTERRUP-
TED, ALWAYS LET THE FAN STILL OPERATE FOR APPROXIMATELY 30 SECONDS AFTER
CUTTING-OUT THE POWER SUPPLY (EITHER MANUAL DISTRIBUTOR P10 OR ELECTRI-
CAL DISTRIBUTOR E11), IN ORDER TO FULLY ELIMINATE THE PRODUCT MIXTURE FROM
THE DISTRIBUTING DEVICES, SO PREVENTING ANY POSSIBLE ANOMALOUS DRIPPING
FROM TAKING PLACE.
• The operator must:
a. Shake the mixture in the tank before starting the treatment, re-circulating it completely for as long
as it takes to make it homogeneous.
b. Check the orientation of the distributors (hands, guns and/or fishtails) of the distribu-
tion device (sprayhead) in relation to the dimensions, the shape and the thickness
of the vegetation to be treated.
c. Continue to shake the mixture until the treatment is resumed should the intervention momentarily
be interrupted. If the utilisation is to be deferred, check that the filter cartridge is clean before
resuming and agitate the mixture that has remained in the tank.
d. Ensure that the hand wash supplementary tank is filled with clean water after each filling operation.
e. Make use of individual protections identical to those envisaged for the preparation of mixtures if
the tractor is not equipped with a pressurised cabin with aeration filters.
f. wash immediately all the elements that might have become contaminated during the treatment,
promptly remove the polluted garments and interrupt the work if these cannot be
immediately replaced.
