Circor ALLWEILER NI Series User Manual

Appendix
9 Appendix
9.1 Sectional drawings
9.1.1 Auxiliary connections
Abbreviation
Connection
FD1
Pumped medium / emptying
FF1 Filling
FV1
Filling / Bleeding
L0 Leak egress
PM1 Pressure gauge
PM2 Pressure gauge
Tab. 13 Abbreviations of the connection designations
9.1.2 Part numbers and designations
Part no. Designation
102.01 Volute casing
108.01 Stage casing
161.01 Housing cover
171.01 Guide wheel
182.01 Support foot
220.01 Stub shaft
230.01 Impeller
230.02 Impeller, first stage
230.03 Impeller, second stage
341.01 Motor bell housing
400.01 Gasket
400.02 Gasket
411.01 Seal ring
411.02 Seal ring
411.03 Seal ring
411.04 Seal ring
411.05 Seal ring
411.06 Seal ring
411.07 Seal ring
412.01 O-ring
433.01 Mechanical seal
502.01 Wear ring
509.01 Intermediate ring
509.02 Intermediate ring
510.01 Spacer ring
Part no. Designation
514.01 Threaded ring
515.01 Clamping ring
525.01 Spacer sleeve
565.01 Rivet
672.01 Vent
686.01 Guard sheet
686.02 Guard sheet
710.01 Pipe
801.01 Flanged motor
892.01 Foot plate
901.01 Hexagon head bolt
901.02 Hexagon head bolt
901.04 Hexagon head bolt
901.10 Hexagon head bolt
901.11 Hexagon head bolt
901.12 Hexagon head bolt
901.21 Hexagon head bolt
902.01 Stud bolt
902.02 Stud bolt
902.10 Stud bolt
903.01 Screw plug
903.02 Screw plug
903.03 Screw plug
903.04 Screw plug
903.06 Screw plug
903.07 Screw plug
904.05 Grub screw
914.06 Cheese head screw
914.10 Cheese head screw
920.01 Nut
920.02 Nut
920.04 Nut
920.10 Nut
922.01 Impeller nut
936.01 Spring ring
30 NI series BA-2021.06 en-US 550 113 – 146-900/E
