6. TECHNICAL FEATURES
Power supply
Mode self-powered
Rated voltage 230V ~ ± 20%
Frequency 50Hz - 60Hz , ±5%
Maximum power consumption 6 VA
Installation category CAT III 300V
RCCB
Rated voltage
REC4-2P, REC4-C-2P 230 V ~
REC4-4P, REC4-C-4P 400 V ~
Rated current (In)
REC4-2P-40-30, REC4-C-2P-40-30 40 A
REC4-2P-63-30, REC4-C-2P-63-30 63 A
REC4-2P-40-300, REC4-C-2P-40-300 40 A
REC4-2P-63-300, REC4-C-2P-63-300 63 A
REC4-4P-40-30, REC4-C-4P-40-30 40 A
REC4-4P-63-30, REC4-C-4P-63-30 63 A
REC4-4P-40-300, REC4-C-4P-40-300 40 A
REC4-4P-63-300, REC4-C-4P-63-300 63 A
Sensitivity (IΔn)
REC4-2P-40-30, REC4-C-2P-40-30
30 mA
REC4-2P-63-30, REC4-C-2P-63-30
REC4-2P-40-300, REC4-C-2P-40-300
300 mA
REC4-2P-63-300, REC4-C-2P-63-300
REC4-4P-40-30, REC4-C-4P-40-30
30 mA
REC4-4P-63-30, REC4-C-4P-63-30
REC4-4P-40-300, REC4-C-4P-40-300
300 mA
REC4-4P-63-300, REC4-C-4P-63-300
Resistance to surges
class A , AC: 250A 8/20μs
class S: 3000A 8/20μs
Resistance to short-circuits Inc : 10000A a 230/400V with gB 80A fuse
Class A (IEC 61008.1)
Number of poles
REC4-2P, REC4-C-2P 2
REC4-4P, REC4-C-4P 4
Rated marking and brealing capacity Im : 500 A
Working frequency 50 / 60 HZ
Measurement circuit
Models REC4-2P-xx-30: The leakage current will be supervised by measuring the resistance downstream of the RCCB.
Sensitivity Rd and Rd0 RCCB response
30 mA
Rd < 8 KΩ no reclose
Rd0 > 16 KΩ reclose
User interface
LEDs 2 LED : AUTO in green and REC in red
Output (REC4-C model)
Type AC12
Maximum voltage 300 V ~ / 300 V
