24-30
Page 50
Serials w/ MCU 19900-001
EFFECTIVITY:
CIRRUS AIRPLANE MAINTENANCE MANUAL MODELS SR22 AND SR22T
01 Jan 2012
(4) Installation - ALT 2 Field Control Module
(a) Acquire necessary tools, equipment, and supplies.
(b) Position field control module under retainer lip and secure with screws and washers.
(c) Position bus bar 9 to chassis and secure with spacers, washers, and nuts.
(d) Install bolt, washers, and nuts securing ALT 2 cable and bus bar 9 to chassis.
(e) Apply Loctite to upper RH standoff and secure to chassis floor with screw. Position sleeve
over standoff.
(f) Position bus bar 8 to chassis and secure with spacers, washers, and nut.
(g) Position bus bar and terminal ring 736 to power diode.
(h) Connect wire harness to field control module.
(i) Install circuit board assembly. (Refer to 24-30)
(j) Install MCU cover. (Refer to 24-30)
(k) Connect battery 1. (Refer to 24-30)
(l) Perform Operational Inspection - Master Control Unit. (Refer to 24-30)
(m) Install engine cowling. (Refer to 71-10)
Description P/N or Spec. Supplier Purpose
Loctite® 222 Any Source Fuse installation.
