Cirrus SR22T Maintenance Manual

CIRRUS AIRPLANE MAINTENANCE MANUAL MODELS SR22 AND SR22T
24-30
Page 51
Serials w/ MCU 19800-001
EFFECTIVITY:
U. Field Control Module - Serials w/ MCU 19800-001 (See Figure 24-307)
The ALT 1 and ALT 2 field control modules are integral to the MCU. The ALT 1 field control module is
located on the upper chassis. The ALT 2 field control module is located on the lower, RH side of chas-
sis.
(1) Removal - Field Control Module
(a) Set BAT 1, BAT 2, and AVIONICS switches to OFF positions.
(b) Remove engine cowling. (Refer to 71-10)
(c) Disconnect battery 1. (Refer to 24-30)
(d) Remove MCU cover. (Refer to 24-30)
(e) Disconnect wire harness from field control module.
(f) Remove nuts securing field control module to chassis. Remove field control module from
airplane.
(2) Installation - Field Control Module
(a) Position field control module to chassis and secure with nuts.
(b) Connect wire harness to field control module.
(c) Install MCU cover. (Refer to 24-30)
(d) Connect battery 1. (Refer to 24-30)
(e) Perform Operational Inspection - Master Control Unit. (Refer to 24-30)
(f) Install engine cowling. (Refer to 71-10)
01 Jan 2012

Cirrus SR22T Specifications

General

Manufacturer	Cirrus Aircraft
Engine	Continental TSIO-550-K
Horsepower	315 hp
Max Takeoff Weight	3, 600 lbs
Service Ceiling	25, 000 ft
Cabin Width	49 in
Cabin Height	50 in
Seating Capacity	4
Avionics	Cirrus Perspective+ by Garmin
Category	Single-engine piston aircraft
Propeller	Hartzell 3-blade composite
Wingspan	38 ft 4 in
Length	26 ft
Height	8 ft 11 in
Maximum Cruise Speed	213 KTAS
Fuel Capacity	92 gallons
Stall Speed	64 knots
Safety Features	Cirrus Airframe Parachute System (CAPS)
Cruise Speed	183 knots
