Cirrus SR22T Maintenance Manual

24-30
Page 52
Serials w/ MCU 19900-001
EFFECTIVITY:
CIRRUS AIRPLANE MAINTENANCE MANUAL MODELS SR22 AND SR22T
01 Jan 2012
V. Circuit Board Assembly - Serials w/ MCU 19900-001 (See Figure 24-307)
(1) Removal - Circuit Board Assembly
(a) Set BAT 1, BAT 2, and AVIONICS switches to OFF positions.
(b) Remove engine cowling. (Refer to 71-10)
(c) Disconnect battery 1. (Refer to 24-30)
(d) Remove MCU cover. (Refer to 24-30)
(e) Disconnect P134 and P126 connectors from circuit board.
(f) Remove screws securing circuit board to mount.
(g) Remove nuts and clamps securing wire harness to mount.
(h) Remove screws securing mount to chassis standoffs.
(2) Installation - Circuit Board Assembly
(a) Position mount to chassis standoffs and secure with screws.
(b) Position circuit board assembly to mount and secure with screws.
(c) Position wire harness clamps to mount and secure with nuts.
(d) Connect P134 and P126 connectors to circuit board.
(e) Install MCU cover. (Refer to 24-30)
(f) Connect battery 1. (Refer to 24-30)
(g) Perform Operational Inspection - Master Control Unit. (Refer to 24-30)
(h) Install engine cowling. (Refer to 71-10)
