GENERAL OVERVIEW
A1
Powered by batteries
A2
Powered by mains with power supply and rechargeable batteries
A3
Powered by mains with power supply
PARTS
1
MyEVO motorised lock
2
“Door Status” device
3
Battery holder
4
Internal button group
5
External keypad group
6
Power supply (input V100÷240 V DC, 90÷350 V DC. Output: 30W, 24V DC, 1.3 A)
7
Cable guard
A1
A2
A3
5
4
1
2
3
5
4
1
2
3
6
24VCC/30W
24VCC/30W
5
4
1
2
7
6
