Overview of the Router 1-3
Hardware Features
Figure 1-1 Model 2501 Router Rear Panel
Figure 1-2 Model 2502 Router Rear Panel
H4262
Ethernet
AUI LED
Ethernet
AUI port
(DB-15)
Console
port (RJ-45)
Auxiliary port
(RJ-45)
On/off
switch
Power
Synchronous
serial LEDs
Synchronous
serial ports
(DB-60)
System
OK LED
H6585
Token Ring
port (DB-9)
Console
port (RJ-45)
Auxiliary port
(RJ-45)
On/off
switch
Power
Synchronous
serial ports
(DB-60)
Token Ring
LED
Synchronous
serial LEDs
System
OK LED
