1-6 Router Installation and Configuration Guide
System Specifications
Figure 1-7 Model 2515 Router Rear Panel
System Specifications
The system specifications of the routers are listed in Table 1-2.
Table 1-2 System Specifications
Description Specification
Dimensions (H x W x D) 1.75 x 17.5 x 10.56 in. (4.44 x 44.45 x 26.82 cm),
one rack unit
Weight 10 lb (4.5 kg)
Input voltage, AC power supply
Current
Frequency
Power dissipation
100 to 240 VAC
1.2 to 0.6A
50/60 Hz
40W (maximum), 135.5 Btus
1
/hr
Input voltage, DC power supply
Current
Power dissipation
40W, 40 to 72 VDC
1.5 to 1.0A
40W (maximum), 135.5 Btus/hr
Processor 20-MHz Motorola 68EC030
On/off
switch
Power
H6590
System
OK LED
Token Ring
LEDs
Synchronous
serial LEDs
Synchronous
serial ports
(DB-60)
Token Ring
ports (DB-9)
Console
port (RJ-45)
Auxiliary port
(RJ-45)
