Overview of the Router 1-5
Hardware Features
Figure 1-5 Model 2513 Router Rear Panel
Figure 1-6 Model 2514 Router Rear Panel
H6588
TOKEN RING
Token Ring
port (DB-9)
Ethernet
AUI port
(DB-15)
Synchronous
serial ports
(DB-60)
Token Ring
LED
Power
On/off
switch
Ethernet
AUI LED
Synchronous
serial LEDs
System
OK LED
Console port
(RJ-45)
Auxiliary port
(RJ-45)
Synchronous
serial ports
(DB-60)
On/off
switch
Power
H6589
Ethernet
AUI ports
(DB-15)
Ethernet
AUI LEDs
Synchronous
serial LEDs
System
OK LED
Console
port (RJ-45)
Auxiliary port
(RJ-45)
