Cisco 2600 Series Overview

1-11
Cisco 2600 Series Routers Hardware Installation Guide
OL-2171-06
Chapter 1 Overview of Cisco 2600 Series Routers
System Specifications
Figure 1-12 Interface Numbering in Cisco 2691 Routers
Voice Interface Numbering
Voice interfaces are numbered as follows:
chassis-slot/voice-module-slot/voice-interface
If a 4-channel voice network module is installed in chassis slot 1, the voice interfaces are:
• 1/0/0—Chassis slot 1/Voice module slot 0/Voice interface 0
• 1/0/1—Chassis slot 1/Voice module slot 0/Voice interface 1
• 1/1/0—Chassis slot 1/Voice module slot 1/Voice interface 0
• 1/1/1—Chassis slot 1/Voice module slot 1/Voice interface 1
System Specifications
62101
SEE MANUAL BEFORE
INS
TALLATION
AL
CD
LP
RD
TD
SE
E MANU
AL BEFORE
INSTALLATION
D
S
U
5
6
K
AL
CD
LP
RD
TD
SEE MANUAL BEFORE
INSTALLATION
D
S
U
5
6
K
E
N
V0
BA
N
K
4
B
AN
K
3
B
AN
K
2
B
A
N
K 1
B
AN
K
0
NM-HDV
V
W
IC
2M
F
T
-E
1
S
E
E
M
A
N
U
A
L
B
E
F
O
R
E
IN
S
T
A
L
L
A
T
I
O
N
C
TR
L
R
E2
C
T
R
L
R
E
1
A
L
L
P
C
D
T1 1/1
T1 1/0
FastEthernet 0/1
FastEthernet 0/0
BRI 0/0
Serial 0/2
Compact Flash slot
Serial 0/1
Serial 0/0
Table 1-6 Cisco 261x, Cisco 262x, and Cisco 265x System Specifications
Description Specification
Dimensions (H x W x D) 1.69 x 17.5 x 11.8 in. (4.3 x 44.5 x 30 cm), one rack unit height
Weight 10.25 lb (4.66 kg)
Input voltage, AC power supply
Current
Frequency
Power dissipation
100 to 240 VAC
1.5 A
47 to 63 Hz
75 W (maximum), 260 Btus
1
/hr
Input voltage, DC power supply
Current
Power dissipation
–38 to –75 VDC
2.0 A
75 W (maximum), 260 Btus/hr
Operating environment 32 to 104° F (0 to 40° C)
Nonoperating temperature –40 to 158° F (–40 to 70° C)
Operating humidity 5 to 95 percent, noncondensing
Noise level 38 dBa (minimum)
