2-19
Cisco 3200 Series Router Hardware Upgrade Guide
OL-15983-01
Chapter 2 Replacing Cards in the Cisco 3230 ISR Rugged Enclosure
Card Replacement Process
Reattaching the Antenna End Cap
To reattach the antenna end cap, follow these steps:
Step 1 If you have added one or more WMICs, remove two of the corresponding plugs from the antenna end
cap and replace them with RP-TNC connectors.
Step 2 Attach the antenna cables to the antenna end cap, as shown in Figure 2-2.
Step 3 Attach the identification labels for the antennas to the antenna end cap.
Step 4 Use a 3/8-inch socket wrench to secure the antenna end cap with 4 1/4-20x1.25-inch-long bolts. The
torque range for the antenna end cap bolts are 58 to 68 in-lb.
Applying New I/O End Cap Function Labels
To apply new I/O end cap function labels, follow these steps:
Step 1 Label the WMIC console ports.
Step 2 If you have more than one WMIC installed in the router, remove the W2 plate on the I/O end cap and
replace it with the DB-9 console connector.
