DescriptionSignalEthernet Port
Pin
No connectionTermination
network
7
No connectionTermination
network
8
Connect the Console
Warning: Do not work on the system or connect or disconnect cables during periods of lightning activity.
Statement 1001
Warning
Your Cisco SNS-3515 or Cisco SNS-3595 appliance has a DCE-mode console port for connecting a console
terminal to your appliance. The appliance uses a DB-9 serial connector for the console port.
The console port on the Cisco SNS-3515 or Cisco SNS-3595 appliance includes an EIA/TIA-232 asynchronous
serial (DB-9) connector. This serial console connector (port) allows you to access the appliance locally by
connecting a terminal—either a PC running terminal-emulation software or an ASCII terminal—to the console
port.
To connect a PC running terminal-emulation software to the console port, use a DB-9 female to DB-9 female
straight-through cable.
To connect an ASCII terminal to the console port, use a DB-9 female to DB-25 male straight-through cable
with a DB-25 female to DB-25 female gender changer.
To connect a terminal or a PC running terminal-emulation software to the console port on the Cisco SNS-3515
or Cisco SNS-3595 appliance:
Step 1 Connect the terminal using a straight-through cable to the console port.
Step 2 Configure your terminal or terminal-emulation software for 9600 baud, 8 data bits, no parity, 1 stop bit, and no hardware
flow control.
Connect the Keyboard and Video Monitor
Do not work on the system or connect or disconnect cables during periods of lightning activity.
Statement 1001
Warning
This section describes how to connect a keyboard and video monitor to the Cisco SNS-3515 or Cisco SNS-3595
appliance.
You can connect the keyboard and video monitor to the Cisco SNS-3515 or Cisco SNS-3595 appliance using
the KVM connector available in the front panel of the Cisco SNS-3515 or Cisco SNS-3595 appliance. A KVM
cable is shipped along with the appliance that provides two USB, one VGA, and one serial connector.
Cisco Secure Network Server 3500 Series Appliance Hardware Installation Guide
22
Install the Cisco SNS 3515 and Cisco SNS 3595 Hardware Appliances
Connect the Console
