Cisco 3500 Series User Manual

CONTENTS
Cisco SNS 3500 Series Appliance Overview 1
CHAPTER 1
Cisco SNS 3500 Series Appliances 1
LED Indicators on Cisco SNS 3515 and 3595 Appliances 1
Cisco SNS-3515 and SNS-3595 Appliances Hardware Specifications 1
Cisco SNS-3515 or 3595 Appliance Front Panel View 2
Cisco SNS 3515 or SNS 3595 Appliance Back Panel View 5
Internal Diagnostic LEDs 7
Regulatory Compliance 8
Before You Begin 9
CHAPTER 2
Safety Guidelines 9
Unpack and Inspect the Server 10
Prepare for Server Installation 11
Installation Guidelines 12
Rack Requirements 12
Equipment Requirements 13
Slide Rail Adjustment Range 13
Server Specifications 13
Physical Specifications 13
Environmental Specifications 13
Power Specifications 14
Install the Cisco SNS 3515 and Cisco SNS 3595 Hardware Appliances 15
CHAPTER 3
Install the Cisco SNS 3515 and Cisco SNS 3595 Hardware Appliances 15
Install the Cisco SNS 3515 or 3595 Appliance in a Rack 15
Install the Side Rails 16
Cisco Secure Network Server 3500 Series Appliance Hardware Installation Guide
iii

Cisco 3500 Series Specifications

General

Product Type	Switch
Form Factor	Rack-mountable
Operating System Support	Cisco IOS
Ports	24 or 48 10/100 ports
Uplink Ports	2 or 4 Gigabit Ethernet uplinks
MAC Address Table Size	8000 entries
Power Supply	Internal
Features	VLAN support, QoS
Storage	See Flash Memory
Network Interfaces	Gigabit Ethernet
