Cisco 3600 Series User Manual

Connecting Digital Modem Network Modules to a Network 10-13
Installing 6-Port MICA Modules
Step 2 Hold the MICA module with the connector edge at the bottom and the
polarization notch at the right.
Step 3 Tilting the MICA module toward you at about a 45-degree angle, insert it into a
socket, beginning with the empty socket closest to you. (See Figure 10-8.) Rock
it downward, using the minimum amount of force required. (See Figure 10-9.)
When the MICA module is properly seated, the socket guide posts fit through
the alignment holes, and the spring clips click into place.
Step 4 Ensure that the MICA module is straight and that the alignment holes line up
with the plastic guides on the socket. It is normal to feel some resistance, but do
not use excessive force on the MICA module, and do not touch the surface
components.
Step 5 Repeat Step 2 through Step 4 for any additional MICA modules.

Cisco 3600 Series Specifications

General

Operating System	Cisco IOS
Series	3600
Type	Modular Router
Interfaces	Ethernet, Fast Ethernet, Serial, ISDN
Routing Protocols	RIP, OSPF, EIGRP, BGP, IS-IS
Redundancy	Optional redundant power supply
Management	CLI, SNMP, Telnet
Weight	Varies depending on the specific model
Power Supply	AC or DC, optional redundant power supply
