Chapter 2 Installation
Installing the CPE On a Wall
Step 1 Locate the screw template. The template is used to align the mounting screw holes
and is also used as a guide to make sure the screws are installed into the desktop
with proper clearance.
Note The template has adhesive to hold it in place while you drill holes
underneath the desktop. If you will be using the same screw template
to install several CPEs, do not use the adhesive. In this case, hold the
template in place with your hand while you drill the screw holes and
insert the screws.
Step 2 Position the screw template so that the two side-by-side slots are facing away from
the floor. (See Figure 2-3.) This ensures the cables will face towards the floor
after they are connected.
Note Do not attach the screw template to the wall yet.
