Chapter 3 Installing the Exterior Cosmetics
Overview of the Exterior Cosmetics
Figure 3-2 shows the exterior cosmetics for the rear side of a Cisco NCS 6008 chassis.
Figure 3-2 Exterior Cosmetic s—Rear Side of Chassis
1 Rear exhaust air deflector 3 Right door
2 Left door
1
2
3
303589
