Using Profiles with Cisco 700 Series Routers 2-3
System Mode Parameter Set
All profiles are based on the profile template and inherit the system-level values. When you
create a new profile, its default values are taken from the profile template.
System Mode Parameter Set
System mode parameters affect the router as a system. Table 2-1 lists the system
parameters.
Profile Mode Parameter Set
Changes madeto profile mode parameters in system mode affect the profile template. When
a profile is created, it inherits the matching system mode parameters from the profile
template. Any changes to parameters in profile mode apply only to that profile. Changes
made to profile parameters in system mode are stored in the profile template. When you use
the set user command to create a user-defined profile, the default parameters for the new
profile are taken from system mode.
Table 2-1 System Parameter Set
Caller ID parameters Call waiting PPP
1
parameters
1 PPP = Point-to-Point Protocol
Date and time Country group Screen length
Directory number(s) Address age time Screen echo
Delay time Local and remote access SNMP
2
parameters
2 SNMP = Simple Network Management Protocol
Forwarding mode Phone 1 and 2 SPIDs
3
3 SPID = service profile identifier
Multidestination dialing PPP client password Switch type
Numbering plan PPP client secret System password
Patterns Voice priority Power Source 1 detect
Passthru Compression System name
PPP authentication
